Lab 4

Putting it all together: Transport Slicing

Rogers Executive Workshop 3 — Transport Network

Getting Started

Connecting the ideas from Labs 1 through 3

Lab 4 at a glance

In this lab you will:

  • observe how contention on a shared bottleneck degrades both bandwidth and latency
  • run one guided demo of a transport slice
  • express slice requirements by editing a short SLICE_REQUEST block
  • ask for a low-latency path, a service chain, and an admissible bandwidth request
  • watch the controller realize each request automatically
Nothing here is a new transport mechanism. Lab 4 puts together the ideas from Labs 1 to 3 behind one higher-level interface: you describe the slice you want, and the transport slice controller realizes it.

From earlier labs to Lab 4

  • Lab 1 showed that the network does not have to treat every flow the same way. Transport can give different traffic different treatment.
  • Lab 2 added the control-plane view. Instead of configuring one device in isolation, we can realize policy across a topology.
  • Lab 3 added explicit path control. Traffic does not have to follow the default path; it can be steered through chosen waypoints and along a chosen route.
  • Lab 4 turns those ideas into one abstraction: a transport slice is a service request that asks for both a path and a treatment.
Nothing in this lab is conceptually new in the data plane. The transport slice controller is the "putting it together" piece: it takes the mechanisms you already used in Labs 1 to 3 and realizes them together from one higher-level request.

How the controller puts it together

High-level overview showing a slice request feeding the transport slice controller, which reuses the ideas from Labs 1 to 3 to realize a slice with a chosen path, chosen waypoints, and chosen treatment.
The request is new. The underlying ingredients are the same ones you already used in the earlier labs.
The transport slice controller code is in the _internal directory. If you are curious, check out how it uses the mechanims from Labs 1 through 3. Note that you do not need edit or change it.

Lab 4 topology

Lab 4 topology with h1 and h3 attached to s1, h2 plus mb1 and mb2 attached to s2, and dual-homed router r1 providing a faster alternate path between the two switches.

h1 source · h2 destination · h3 competing flow · mb1 telemetry · mb2 security · r1 alternate-path router

The direct s1→s2 path is slower and bandwidth-limited. The r1 path is faster and uncongested, but ONOS does not choose it by default.

What the middleboxes do

mb1 — telemetry monitor
Reports observed throughput of traffic that visits it.
Its log lighting up confirms traffic really took the requested waypoint.

mb2 — security inspector
Inspects the inner flow and reports [OK] or [ALERT].

The middlebox logs are useful to check if traffic is flowing through the chain. If a log lights up, the slice's waypoint requirement is being realized.

What a slice request looks like

The transport slice controller uses the same mechanisms you learned in Labs 1 to 3, but it exposes a higher-level interface. Instead of configuring each mechanism separately, every exercise asks you to edit one SLICE_REQUEST block in a slice_request.py file:

SLICE_REQUEST = {
    "name":               "express",
    "src":                "h1",
    "dst":                "h2",
    "latency_objective":  "standard",   # "standard" | "low"
    "bandwidth_mbps":     0,            # 0 = best-effort, 1–10 = reserved
    "waypoints":          ["mb1"],      # [] | ["mb1"] | ["mb2"] | ["mb1","mb2"]
}
You are not editing the queueing, ONOS, or SRv6 logic directly. You describe the slice you want in one request, and the controller realizes it using those same underlying mechanisms.

Before you start (1/2)

First: clean up Lab 3 completely.

  1. Exit any running Mininet (Ctrl+D or exit in the Mininet terminal)
  2. Run sudo mn -c in a terminal
  3. Close all Lab 3 terminals

Then work from:

cd ~/labs/lab4
Stay in labs/lab4 for every command in this lab.

Make sure ONOS is running. As done previously, open the ONOS CLI from a new terminal using ssh:

ssh -p 8101 -o HostKeyAlgorithms=+ssh-rsa onos@localhost
# password: rocks

Before you start (2/2)

From the ONOS CLI, verify the required apps are active:

onos> apps -s -a

You should see these three in the list:

org.onosproject.openflow
org.onosproject.fwd
org.onosproject.proxyarp

Then verify that IPv6 forwarding is enabled in fwd:

onos> cfg get org.onosproject.fwd.ReactiveForwarding

Look for ipv6Forwarding in the output — it should show true. If it does not, the switches will not forward SRv6 packets correctly.

The Demo

One guided example before the exercises

Run the demo

From ~/labs/lab4:

sudo python3 demo/run.py

The demo uses a fixed request in demo/slice_request.py — you will be asked to open and read it; do not edit it.

The runner walks through four phases and pauses at each one. Follow along in the log files.

If you are familiar with tmux, it can be useful to manage the different terminals; however it is strictly optional.

Exercises

Exercise workflow

  1. From ~/labs/lab4, run:
    sudo python3 exercises/partX/run.py  # <-- replace X e.g, part1, part2, or part3
  2. The runner starts the network, configures SRv6, and starts traffic automatically — so you can see the problem first
  3. When the runner pauses, open exercises/partX/slice_request.py and edit the SLICE_REQUEST block
  4. Press Ctrl+S to save slice_request.py, then press ENTER in the runner
  5. The slice is applied and you observe the effect
  6. The slice is torn down so you can see the behavior revert

If a request is invalid or rejected, the runner prints the error and waits for you to edit and retry.

If the file is not saved yet, many editors show a small white dot in the tab. Save first with Ctrl+S or the runner will reuse the old request.

Exercise 1 — Low-latency path

mininet> exit → sudo mn -c → cd ~/labs/lab4

Goal: ask for a lower-latency service from h1 to h2 while keeping the telemetry monitor in the chain.

The runner shows you contention first, then asks you to edit exercises/part1/slice_request.py.

sudo python3 exercises/part1/run.py
solutions/part1/slice_request.py

Watch these logs:

tail -F /tmp/iperf_h1.log
tail -F /tmp/iperf_h3.log
tail -F /tmp/ping_h1_h2.log
tail -F /tmp/mb1_bandwidth.log

Exercise 2 — Service chain

mininet> exit → sudo mn -c → cd ~/labs/lab4

Goal: keep the standard path and best-effort bandwidth, but route traffic through both middleboxes in this order:

telemetry monitor → security inspector → destination

The runner starts traffic first, then asks you to edit exercises/part2/slice_request.py.

sudo python3 exercises/part2/run.py

Watch these logs:

tail -F /tmp/iperf_h1.log
tail -F /tmp/iperf_h3.log
tail -F /tmp/mb1_bandwidth.log
tail -F /tmp/mb2_security.log

Exercise 3 — Admission control

mininet> exit → sudo mn -c → cd ~/labs/lab4

The runner installs a fixed 8 Mbps slice for h1, then asks you to submit a competing request for h3. It retries until your request is admitted.

sudo python3 exercises/part3/run.py   # edit exercises/part3/slice_request.py when prompted

This controller uses first-come-first-served: the baseline slice keeps its reservation and your request is evaluated only against what remains. That raises a useful question — what if the second request were actually more important? A smarter controller might weigh priority, preemption, or SLA tier.

Further reading: M. Sulaiman et al., Coordinated Slicing and Admission Control using Multi-Agent Deep Reinforcement Learning, IEEE TNSM, 20(2), 2023.

Troubleshooting

The runner hangs or pingAll fails at startup.
Restart ONOS: sudo docker restart onos. Wait 2–3 minutes, then rerun.

Switches are not forwarding traffic.
Check that ipv6Forwarding is true: cfg get org.onosproject.fwd.ReactiveForwarding

The request file won't load.
Edit only the SLICE_REQUEST block and keep it a valid Python dictionary.

A middlebox log stays silent.
Confirm that middlebox is listed in waypoints in your request.

The runner fails with RTNETLINK answers: File exists or similar.
A previous Mininet run was not cleaned up. Run sudo mn -c and restart from ~/labs/lab4.

Summary

Lab 4 is where Labs 1–3 come together to illustrate the concepts behind simple transport slicing:

  • Lab 1 — programmable match/action rules steer traffic to the right queue
  • Lab 2 — an SDN controller translates one service request into concrete switch rules
  • Lab 3 — SRv6 steers traffic onto the right path and through the right waypoints

A single request expressing a path objective, a service chain, and a bandwidth guarantee and a transport slice controller that realizes it.

Curious to go further? See the optional Further Reading page for recent work on slice monitoring, fine-grained telemetry, and programmable offloading.

You Completed Workshop 3: Transport Networks

Achievement unlocked meme used as a humorous finish to Lab 4.

Across the workshop, you:

  • learned how SDN enables programmable and flexible transport networks
  • worked hands-on with the key enablers such as OVS, Mininet, ONOS, and SRv6
  • saw how those pieces can come together in a simplified transport slice controller

Congratulations on completing Workshop 3: Transport Networks!
